Tools and materials required

before you begin, prepare the following items:

• high bay LED lamps

• ladders or scaffolding (for high ceilings)

• screwdriver or drill

• wire stripping pliers

• measuring pen

• electrical tape

• terminal

• mounting hardware (usually included with the luminaire)

• safety gloves and goggles

step 1: Turn off the power

safety first! Before handling any wires, turn off the power to the main circuit breaker. Use a voltage tester to verify that the wire is not energized.

Step 2: Choose the right installation method

high bay light different installation methods can be adopted according to the type of lamp and ceiling structure:

A. Chain or cable installation

• secure the mounting hook to the ceiling joist.

• Hang the lamp with a chain or cable.

• Adjust the height as required.

B. Direct installation (open or concealed)

• fix the lamp directly to the ceiling with screws.

• Make sure that the mounting surface is strong enough to bear its weight.

C. Pendant installation

• use a rigid conduit or suspension kit to hang the light fixture from the ceiling.

• Suitable for areas requiring height adjustment



step 3: Install the line of high bay lights

1. remove lamp housing-Open the wiring compartment.

2. Connecting wires-Connect the wires of the lamp to the wires on the ceiling:

• Black (Fire/Phase) → Black




• white (zero line) → white




• green/bare wire (ground wire) → green/bare wire

3. with terminal

   -Twist the wires together and cover with terminal blocks.

   Secure wire

4. -ensure no exposed wire remains.

5. the

6. to replace the cover -hold the clamp housing.



step 4: Test the lights

• restore power supply.

• Turn on the light and make sure it is working properly.

• If the light does not light up, please check for flickering or loose wiring.



Step 5: Adjust and fix the device

• make sure the lamps are level and in the correct position.

• Tighten all screws and mounting hardware.

Safety tips

✔Please hire a licensed electrician for complex installation.

conclusion

following the correct steps, installing high bay LED lights is a simple process. The right installation ensures that your work space has bright and efficient lighting while ensuring safety. If you are unsure about any step, it is always a good idea to consult our engineers.
